25G-SFP28-LR 10km 1310nm Duplex LC UPC SMF Transceiver Module,Compatible with Cisco,Arista,Juniper,NVIDIA/Mellanox,IBM,Dell,HPE
Max. Data Rate:25.5Gbps
Media Type:SMF
Form Factor:SFP28
Wavelength:1310nm
Modulation:NRZ
Max. Cable Distance:10km@SMF
Core Size: G.652
Connector:Duplex LC
Transmitter Type:DFB 1310nm
Receiver Type:PIN
DDM/DOM:Supported
CDR (Clock and Data Recovery): TX & RX Built-in CDR
Inbuilt FEC: Yes
Commercial Temperature Range:0 to 70°C (32 to 158°F)
TX Power:-4~-2dBm
Receiver Sensitivity:<-12dBm
Typical Power Consumption:≤1.2W
Receiver Overload:2dBm
Extinction Ratio:>3.5dB
Power Budget:8dB
EMC (Electro Magnetic Compatibility):Supported
Protocols: SFF-8472,SFF-8024,MSA Compliant
Warranty:5 Years
